Type: Vertical, three-rank, five-stage, oil-free lubrication, water-cooling and piston
Exhaust capacity: 180 m3/h (according to suction state)
Medium : Dry oxygen
Inlet Temperature: ＜40℃
Max Working Pressure: 16.17 MPa（165kgf/cm2)
Piston travel: 180 mm
Consumption of cooling water: 6T/hr
Revolution of compressor: 232r.p.m
Revolution of electric motor: 960 r.p.m
Power of electric motor: 55KW
Matching motor: 380V (three phase） 50Hz |
