Type: Vertical, three-rank, three-stage, oil-free lubrication, water-cooling and piston
Exhaust capacity: 750 m3/h (according to suction state)
Medium: Dry oxygen（The dew point of the suction gas <40 o）
Suction condition:
Pressure: 1Kpa
Temperature: ≤20 deg. C
Final pressure: 3.04MPa（30Kgf/ cm2）
Piston travel: 180 mm
Revolution of crankshaft: 590 r/min
Dia. of cylinder:
Stage 1 Ø320 mm
Stage 2 Ø200 mm
Stage 3 Ø120 mm
Shaft power: 145 KW
Consumption of cooling water: ～16t/h
Direction of revolution: Counterclockwise as viewed from the oil pump
Way of transmission : Directly connection in the way of the stiff coupling against the electric motor
Motor:
Model Y355L1-10
Power 160 KW
Voltage 380 V 50Hz |
